| Audio | 7.1 CH HD Audio (Realtek ALC4050H+ALC1220) |
| Chipset | AMD TRX40 |
| CPU Support | Supports AMD Socket sTRX4
- Intersil Digital PWM
- 16 Power Phase design
- Supports ASRock Hyper BCLK Engine II |
| Form Factor | - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
- 8 Layer PCB
- 2oz Copper PCB |
| Graphic | - n/a |
| LAN | 1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125AG):
1 x Intel® Gigabit LAN 10/100/1000 Mb/s (1 x Intel® I211AT): |
| Memory Support | Quad Channel DDR4 Memory Technology
- 8 x DDR4 DIMM Slots |
| Slots | - 3 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3/PCIE4: single at x16 (PCIE1); dual at x16 (PCIE1) / x16 (PCIE3); triple at x16 (PCIE1) / x16 (PCIE3) / x16 (PCIE4)*
- 1 x PCI Express 4.0 x1 Slot
- Supports AMD 3-Way CrossFireX™ and CrossFireX™
- Supports NVIDIA® 3-Way SLI™ and SLI™
- Supports NVIDIA® NVLink™ with dual NVIDIA® GeForce RTX series graphics cards**
- 1 x M.2 Socket (Key E) with the bundled WiFi-802.11ax module
- 15μ Gold Contact in VGA PCIe Slots (PCIE1, PCIE3 and PCIE4) |
| Storage | - 8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
- 1 x Hyper M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s)*
- 1 x Hyper M.2 Socket (M2_2), supports M Key type 2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4 (64 Gb/s) |
